BN-200 Small Size UBLOX M8030 Chipset GPS Module Antenna GPS GLONASS Dual GNSS Module


Local Warehouse
Cheapest Prices Worldwide
Fast Postage Available
100% Customer Satisfaction
Quality Guarantee
Buy Direct From Supplier
Hurry up! Just 6 items left in stock


Parameter Specification
Electrical Characteristics Chipset u-blox M8030-KT
Receiving Format GPS,GLONASS,Galileo,BeiDou,QZSS and SBAS
Frequency GPS L1, GLONASS L1, BeiDou B1,SBAS L1, Galileo E1
Channels 72 Searching Channel
Sensitivity Tracking -167dBm
Reacquisition -160dBm
Cold start -148dBm
Hot start -156dBm
Accuracy Position Horizontal 2.0 m CEP 2D RMS SBAS Enable (Typical Open Sky)
Velocity 0.1m/sec 95% (SA off)
Timing 1us synchronized to GPS time
Acquisition Time Cold Start 26s
Warm start 25s
Hot start 1s
Data and Update Rate Support Rate 4800bps to 921600bps,Default 9600bps
Data Level Default TTL level
Data Protocol NMEA-0183 or UBX, Default NMEA-0183
Single GNSS 1Hz-18Hz
Concurrent GNSS 1Hz-10Hz,Default 1Hz
Operational Limits Altitude 50,000m Max
Velocity 515m/s Max
Acceleration Less than 4g
Power consumption VCC DC Voltage 3.0V-5.5V,Typical: 5.0V
Current Capture 50mA/5.0V
Mechanical Specifications Dimension 20mm*20mm*6mm
Weight 5.2mm
Connector 1.00mm spacing 4pins connector
Environment Operating temp -40 °C ~ +85°C
Storage Temp -40°C ~ +105°C
LED built-in LED TX LED:blue.The data output, TX LED flashing
PPS LED:red.PPS LED not bright when GPS not fixed,flashing when fixed

Package included:

1 x BN-200 Small Size UBLOX M8030 Chipset GPS Module
